Wood, acrylic, bamboo, cloth (not cotton, canvas works best), leather, kraft paper, hard plastic, black lacquered metal/ceramic/stone, glass (need to be blacked out), food
After-Sales Team
Professional support
Free Engraving Files
Provide free engraving file
Free Delivery
Free delivery
（Not include tax）
Warranty
1-Year warranty policy
ORTUR LASER MASTER 2 PRO S2
Speed up to 15,000mm/min
Integrated Air Assist, Dual Fans, Foldable Focal Gauge
All in 235g Weight
Ultimate Engraving Experience with Precision
The Improved Mechanical Structure
Focal Spot 0.05x0.1mm
Bring Delicate Details at 0.01mm
4 Safety Features
Thousands of tests, just to create a safe operating state
1. Active position protection
2. Stops working when the usb cable is disconnected
3. Emergency stop switch and flame alarm
4. Exposure time detection and limitation
Ortur Laser 1.8 Series Firmware
Ortur Laser 1.8 firmware, qualified for ESP32 MCUs, optimizes the motion algorithm, and increases the maximum stepper motors speed from 4,000mm/min to15,000mm/mm.
Broad Compatibility
It can be used with a variety of engraving software, including Laser GRBL, Light Burn, Windows XP, Windows 7, Windows 8, and Windows 10, as well as Mac and Linux systems (LightBurn, which requires a monthly subscription).
Complete service system makes you easily become the master of laser engraving machine.
Earn money with SINIS
Join tens of thousands of SINIS influencers who are earning money with the SINIS affiliate program.
enjoy subscribing Customer discount
Want discount for your first order?
Don't miss out the latest news from SINISMALL.
Subscribe us!
You can receive a 5% discount on your first purchase！
FIND YOUR ANSWERS HERE
FREQUENTLY ASKED QUESTIONS
What kind of material can be engraved?
What kind of material can be cut? How much is the thickness?
Cardboard, Felt, Stickers, Wood, Acrylic, Bamboo, Cloth, Kraft, Hard Plastic, Leather.
Maximum cutting thickness: black acrylic( 12mm) wood board(20mm).Both of them require multiple engravings.
Can the PCB board be cut?
Yes, the ORTUR laser can cut PCB boards made of acetate. preferably black or green
How to use laser to cut mirror acrylic? is it possible
You can cut opaque mirrored acrylic. Transparent materials cannot be cut and can only be engraved after blackening
Can it engrave metal and stainless steel?
It can engrave the metal after electroplating or spraying (for coating or oxide layer), stainless steel (the effect of stainless steel is better after blackening, note: not etching, but discoloration)
Can it engrave the glass？
The laser can engrave on the glass surface, but the engraving depth is not deep and cannot be cut. Glass engraving is usually difficult to control. You can make a smoother frosted surface by following the steps below: Paste thermal paper on the area to be engraved, and place it on the engraved area to flatten it without wrinkles. Put the glass in the engraving machine to engrave, then remove the glass, tear off the thermal paper, and clean the glass surface. There are other ways to engrave glass on YOUTUBE, such as first layer paint engraving and then wipe off, the engraving effect is very good.
How to choose laser modules?
LU2-2 Electric Power: 7W, Optical Power: 1,000-1,600mW More suitable for novice engraving.
Both long and short focal lengths can be cut and engraved.
However, the LU2-4 LF telephoto has a longer beam waist and higher energy density. On the basis of balance, it is more inclined to cutting, and the maximum cutting is 9MM plywood (LF gas nozzle is equipped, the cut surface is smooth, and there will be no black edges)
The focus of the LU2-4 SF short focus is smaller, and on a balanced basis, it is more inclined to engraving, especially hard materials such as stainless steel.
And an external acrylic laser protective cover, physical protection of laser radiation, you can observe the engraving without laser goggles.
Q2: Are laser engraver suitable for round cutting accessories like electric models?about $54.99?
Yes, they can install that roller. The specific method is to connect the roller to the Y-axis terminal of the motherboard. If the rollers are too high, you can add foot pads.
Q3: Equipped with 5.5W laser head, right? Can I buy and install a second, more powerful laser for this machine?
Yes, with 5.5W-10W laser module.
Replacing the laser head is no problem. Later, we will launch a compatible higher power laser head, you can directly purchase and install it.
Q4: What is the output optical power of the SF LF laser?
Both are about 5.5W, and the maximum power of the whole machine (including the motherboard and motor) is 40W.
