After 10,000 hours of use, the laser's power drops by 15%, but it can still be used for simple engraving. Every 50 hours of operation, the laser should be cleaned with alcohol cotton to maintain its optimal performance.

It varies for each application. It all depends on what you have to work with. Easy-to-burn and hard-to-burn materials are the most common classifications. You also need to keep an eye on the cutting edge's condition.

Cut-through speed and laser power are both critical considerations. For example, cutting at high power and fast speed is recommended for wood-based bamboo acrylic. Chopping at modest speeds and using low-power tools. Burnt edges can be caused by too much power and too little speed. In the user guide, we also go through a few cutting parameters.

1.If the engraving machine is shifted or slanted, the laser operation will immediately be stopped to avoid the laser from firing out the target and inflicting harm;

2.Laser Beam Safety Guard: If the engraving machine or computer malfunctions, the laser beam will continue to emit light and cause the target to catch fire.

3.Protective measures will be taken if the laser has been turned on, but there has been no movement for a long time. When used in low light, the laser will shut off after 100 seconds; when not used in low light, it will shut off between 10 and 60 seconds, depending on the power. A few seconds later, the laser will be turned off.

4.The mainboard will monitor the laser module's input and output current, which will cut off power to the laser module and motor after shutdown. A power source will also be disconnected if it receives an inappropriate amount of voltage.

5.Detection of fire with buzzer alarm

6.Emergency Stop Button

Only the PRO S2 models can be equipped with the (flame detection and emergency stop switch)

OLM2 PRO S2 400X400MM/OLM2 S2 390X410MM/AL2 390X390MM/AL1 180X180MM

1.Plug the TF card into the offline control panel and chop the picture into Gcode command files to engrave offline. To control the engraving, you can alternatively connect to the computer via the WIFI function of the offline control panel instead of using a USB cord. - research and development

2.Second, the Z-Axis Lifting Device (easy to focus, but it will increase the weight of the laser head and affect the engraving speed.)

3.Rotating Rollers on the Y-Axis (this device is needed to engrave cylinders)

4.The casing is wholly encased (If your working space is not enclosed, you need to purchase this fully-enclosed protective cover to fully protect the machine and prevent any visitors from touching the device)

It is possible to cut PCBs from acetate using the ORTUR laser. Preference would be for either black or green.

Acrylic that is both opaque and reflective can be sliced. It is impossible to cut transparent materials; the only way to engrave them is to blacken them beforehand.

Engraving area: S2-390MMX410MM PS2-400MMX400MM

Engraving speed:S2-5000mm/min is the max PS2-10000mm/min is the max

Motherboard :PS2 use the 9th Ortur Laser Motherboard, with 32Bits MC,which is the newest tech in Ortur.

Safe:

S2:

1.Active Position Protection,

2.Exposure Duration Detection and Limitation,

3.Laser Beam Safety Guard.

4.Power Control Systerm

PS2:

1.Active Position Protection,

2.Exposure Duration Detection and Limitation,

3.Laser Beam Safety Guard.

4.Flame Detector

5.Emergency Stop Button

6.Power Control System

The ORTUR series has several advantages over the Other Laser Engravers series, such as a more detailed design of the structure, a sharp focus, square feet, suitable accessories, eye protection, etc. And we've designed our software. At any point, the machine can "develop," and the engraving result will get better and better if the firmware is kept up to date.

ORTUR PS2 includes a power switch enabling a quick shut down of the system (Other Laser Engravers does not). The main board consists of an expansion interface for the XYZ limit switch.

ORTUR's Z-axis focus mechanism is simple and reliable and requires just human control (no tools required, much faster than Other Laser Engravers). The focusing process takes a few seconds, making it one of the fastest in its category.

PS2 is more convenient than a square measuring ruler to see the carving in all directions.

ORTUR features a more precise fixed focus mechanism, which provides additional advantages for engraving.

If you're looking for a way to increase productivity, we're your best bet. Our engraving speed is faster than the Other Laser Engravers series.

We offer a safer machine performance than the Other Laser Engravers series; therefore, we are the best option for you if you want to ensure your safety while using the machine.

For the same price as one Other Laser Engravers, you may get three Ortur products, and our safety features and engraving speed are superior to those of the Xtool series.

All firms selling Ortur items have a one-year warranty; only sinis has a two-year contract).
